Atom
Atom dynamic multi-mode filter
FREE DOWNLOAD ... READ PDF MANUAL
Atom is a dynamic multi-mode filter for KORG prologue, minilogue xd, NTS-1, NTS-1 mkII, NTS-3 and microKORG2. At its core is a modern state variable filter model with five different filter modes (low-pass, high-pass, band-pass, notch, peaking) and smooth yet charismatic sound. In all modes, the filter has the ability to run up to 4 stages in series with auto-scaling resonance: this makes its frequency response slope variable from -12 up to extremely steep -48 dB/octave. Atom also features a built-in sine LFO and an input envelope follower, both of which can be used to modulate the filter cutoff. Note: on first-generation devices, the plugin runs in -24 dB/octave configuration and lacks built-in modulation.
HIGHLIGHTS
- Studio-grade DSP algorithms, calibrated specifically for KORG’s hardware platform.
- Individually chosen mapping for every plugin parameter, providing a very natural feel.
- Built-in lag filters for noise-free, ultra-smooth parameter adjustment.
- Tested and optimized for maximum performance and stability on each individual device type.
COMPATIBILITY
- KORG prologue
- KORG minilogue xd
- KORG NTS-1
- KORG NTS-1 mkII
- KORG NTS-3
- KORG microKORG2
